Heavy Duty Swivel Hook With Latch
A swivel hook with safety latch is a type of rigging hardware commonly used in various lifting and rigging applications. It features a hook that can rotate 360 degrees (swivel) to prevent tangling and allow for easier maneuvering of loads. Besides, it has a latch mechanism to secure the load in place, providing additional safety.
- Material: Forged Carbon or Alloy Steel
- Proof load is 2 times working load limit
- Suitable for positioning of the hook before the load lifted.
- Swivel hooks Min breaking load is 5 times of Working Load Limit.
- Proper design, careful forging, and precision controlled quench and tempering gives maximum strength without excessive weight and bulk.
Specifications
swivel hooks, swivel hook with latch, alloy swivle hoist hooks
| Dimensions (mm) | Working Load Limit (Ton) | Weight (kg) | ||||||
| B | C | O | R | S | T | Carbon | Alloy | |
| 23.8 | 31.8 | 22.3 | 113.5 | 9.5 | 20.5 | 3/4 | 1 | 0.40 |
| 33.0 | 38.1 | 24.6 | 136.5 | 12.7 | 20.5 | 1 | 1 1/2 | 0.58 |
| 41.3 | 44.5 | 25.4 | 152.8 | 15.9 | 21.3 | 1 1/2 | 2 | 1.03 |
| 39.7 | 44.5 | 28.4 | 161.9 | 15.9 | 26.0 | 2 | 3 | 1.29 |
| 44.5 | 50.8 | 34.0 | 188.1 | 19.1 | 35.0 | 3 | 4 1/2 | 2.33 |
| 58.7 | 63.5 | 42.9 | 243.7 | 25.4 | 45.1 | 5 | 7 | 4.72 |
| 60.3 | 69.9 | 52.2 | 282.6 | 28.6 | 53.8 | 7 1/2 | 11 | 7.37 |
| 71.4 | 79.4 | 57.0 | 303.2 | 31.8 | 63.5 | 10 | 15 | 10.63 |
